Description
TECHNICAL PARAMETER | |||
Battery Voltage Range | 40-60Vdc | ||
Max. Charging and Discharging Power | 5.6kW | ||
Battery Type | Li/Lead-acid | ||
Max. Recommended PV Power | 6.0kW | ||
Max. PV Voltage | 500Vdc | ||
Start-up Voltage | 120Vdc | ||
PV Voltage Range | 120-450Vdc | ||
MPPT voltage range | 120-450Vdc | ||
MPPT voltage range at full load | 300-450Vdc | ||
Max. input current | 22A | ||
Number of MPPT trackers/strings per MPP tracker | No | ||
Input voltage range | 220/230Vac | ||
Rated grid frequency | 50/60Hz | ||
Max. charging current | 60A | ||
Max. AC Output Power | 5.6kW | ||
AC output rated current | 22A | ||
Max. output current | 24A | ||
Power Factor | 96% | ||
Displacement Power Factor | 0.9lead…0.9lag | ||
Rated Output Power | 5.0kVA/5.0kW | ||
Max. output current | 22A | ||
Rated AC Output Voltage | 230Vac | ||
Rated AC Output Frequency | 50Hz±0.3Hz/60Hz±0.3Hz | ||
Max. Energy Efficiency | >93% | ||
MPPT Efficiency | 97% | ||
operating temperature | -15° C to 55° C | ||
Protection degree | IP65 | ||
Communication | RS485 | ||
BMS Communication | RS485 | ||
Monitor Module | WIFI/USB | ||
Display | LCD+LED | ||
Grid regulation | VDE-AR-N 4105;G99/1;EN50549-1;CEI 0-21;AS 4777.2;NRS 097-2-1; | ||
Safety regulations | CE(IEC62109-1,2) | ||
Electromagnetic compatibility | EN61000,C2 | ||
Weight (kg) | 25.0kg | ||
Dimension (D×W×H) | 550×378.5×205mm |
