Description
TECHNICAL PARAMETER | |||
Battery Voltage Range | 40-62Vdc | ||
Max. Charging and Discharging Power | 10.0kW | ||
Battery Type | Li/Lead-acid | ||
Max. Recommended PV Power | 14.5kW | ||
Max. PV Voltage | 1000Vdc | ||
Start-up Voltage | 320/350Vdc | ||
PV Voltage Range | 320-1000Vdc | ||
MPPT voltage range | 350-850Vdc | ||
MPPT voltage range at full load | 450-850Vdc | ||
Max. input current | A2/A:26A,B:13A | ||
Number of MPPT trackers/strings per MPP tracker | A:2,B:1 | ||
Input voltage range | 170Vac~290Vac Per phase | ||
Rated grid frequency | 50/60Hz | ||
Max. charging current | 220A | ||
Max. AC Output Power | 10.0kW | ||
AC output rated current | 14.5A per phase | ||
Max. output current | 24A | ||
Power Factor | 96% | ||
Displacement Power Factor | 0.9lead…0.9lag | ||
Rated Output Power | 10.0kVA/10.0kW | ||
Max. output current | 14.5A per phase | ||
Rated AC Output Voltage | 230Vac(P-N) / 400VAC(P-P) | ||
Rated AC Output Frequency | 50Hz±0.3Hz/60Hz±0.3Hz | ||
Max. Energy Efficiency | >91% | ||
MPPT Efficiency | 97% | ||
operating temperature | -25°C to 60°C, ≥ 45℃ Deratng | ||
Protection degree | IP65 | ||
Communication | RS485 | ||
BMS Communication | CAN/RS485 | ||
Monitor Module | WIFI/USB | ||
Display | LCD+LED | ||
Grid regulation | VDE-AR-N 4105;G99/1;EN50549-1;CEI 0-21;AS 4777.2;NRS 097-2-1; | ||
Safety regulations | IEC 62109-1/2,IEC62040-1 | ||
Electromagnetic compatibility | EN61000-6-1,EN61000-6-3 | ||
Weight (kg) | 53.0kg | ||
Dimension (D×W×H) | 750×460×205mm |
