3.6kW Off Grid MPPT Solar Inverter Pure Sine Wave

3.6kW Off Grid MPPT Solar Inverter Pure Sine Wave 3600VA/3600W – Focus on Manufacturers

SolarBatteryforHome.com manufactures and produces solar inverters, which support home solar energy storage linked to solar photovoltaic panels and lithium solar batteries.

SolarBatteryforHome.com is a specialised manufacturer of custom solar off-grid and hybrid inverters, dedicated to creating solar inverter solutions with the highest conversion efficiencies and best quality. Our inverters support digital upgrades (monitoring and management using an app) and offer up to 95% conversion efficiency as well as a 5-year warranty.

3.6kW Off Grid MPPT Solar Inverter Pure Sine Wave 3600VA/3600WBrief

The 3600W off-grid MPPT solar inverter outputs a pure sine wave, compatible with 99.99% of electronic devices, with a conversion efficiency of up to 95%, and adopts perfect protection measures, waterproof, dustproof, anti-radiation, and supports outdoor and indoor wall-mounted installation. The inverter supports MPPT solar power and battery power functions in one, providing uninterrupted power support, which is ideal for home, emergency, industrial and other application scenarios.

3.6kW Off Grid MPPT Solar Inverter Pure Sine Wave 3600VA/3600WFeatures

  • Support WIFI/4G digital upgrade
  • Excellent battery management
  • Support CAN/RS485 communication
  • Built-in MPPT controller, support 40Vdc~450Vdc
  • Maximum input power 18A/5000W
Product Inquiries

Description



TECHNICAL PARAMETER
Rated Output Power 3.6kVA
Rated Output Power 3.6kW
Nominal DC Input Voltage 24Vdc
Input Voltage Waveform Sinusoidal(utility or generator)
Nominal Input Voltage 230Vac
Nominal Input Frequency 50Hz/60Hz(Auto detection)
Efficiency(Line Mode) >95% (Rated R load, battery full charged)
Pass Through Without Battery Yes
Nominal Input Voltage 230Vac
Input Voltage Range Normal mode 90-280Vac, UPS mode 170-280Vac
Max. Charge Current 80A
Over Charge Protection Yes
Max. PV Open Circuit Voltage 500Vdc
PV Voltage Working Range 40V-500Vdc
MPPT Operating Range 40V-450Vdc
Max.input Power 5.0kW
Max. Solar Charging Current 100A
Max. Input Current 18A
Min.startup Voltage 21Vdc
Rated Output Power (VA) 3.6kVA
Rated Output Power (W) 3.6kW
Nominal Output Voltage 220Vac±5%
Nominal Output Frequency (Hz) 50+0.3Hz/60Hz+0.3Hz(Adjustable)
Parallel Capability No
Peak Efficiency >93%
Over-Load Protection (Smps Load) 5.5s@>150%load; 10.5s@105%~150%load
Weight 10.0kg
Dimension (D×W×H) 395×295×129mm
