3kW 5kWh All-in-One Home Battery Backup Energy Storage System

3kW 5kWh All-in-One Home Battery Backup Energy Storage System – Focus on Manufacturers

SolarBatteryforHome.com manufactures and all-in-one home battery backup energy storage system, which is an all-in-one energy storage device with built-in batteries and inverter that supports both off-grid and on-grid functionality, this device can also be referred to as solar energy storage system and home energy storage.

SolarBatteryforHome.com is a professional OEM ODM manufacturer of customised All-in-One Home Battery Backup Energy Storage System with UN38.3/MSDS/UL/CE/FCC certificates, supporting export to more than one hundred countries, and is committed to creating All-in-One Home Battery Backup Energy Storage System with high-performance, cost-effective and high-quality.

3kW 5kWh All-in-One Home Battery Backup Energy Storage SystemBrief

3kW 5kWh all-in-one home battery backup energy storage system built-in BYD lithium iron phosphate class A battery, cycle life up to 5000 +, maximum output power of 3600W, peak output power of 7000W, the output of pure sine wave waveform, 3kW 5kWh all-in-one home battery backup energy storage system supports grid charging and photovoltaic charging, and supports the power supply to the grid, and the surplus power to be sold to the the power company.

3kW 5kWh All-in-One Home Battery Backup Energy Storage SystemFeatures

  • BYD Class A Battery
  • Cycle life 5000+
  • 5 years warranty
  • Built-in pure sine wave inverter
  • Support grid, PV charging
  • 10ms UPS switchover
Product Inquiries

Description



TECHNICAL PARAMETER
Battery Model BYD LiFePO4 Battery
Lifespan 5000+
Waterproof Grade IP21
Battery Capacity 5222.8Wh
Nominal Working Voltage 51.2V
Nominal Input Current 5OA
Max.Operating Current 80A
Over-Voltage Protection 58.4V (Recovery Voltage 54V)
Over-Discharge Protection 45V (Overdrain Recovery 48V)
Max. Output Power (W) 3600W
Peak Output Power (W) 7000W
Output Voltage Waveform Pure Sine Wave
Rated Output Voltage(Vac) (Customizable) 110Vac/120Vac/220Vac-250Vac±5%
Ouput Frequency Range (Customizable) 47±0.3Hz~55±0.3Hz(50Hz); 57±0.3Hz~65±0.3Hz(60Hz);
Max.Efficiency >92%
Charge Mode Supports utility charging, photovoltaic charging
Input Voltage Range (Customized) (170Vac~280Vac)±2%(UPsmode)(90Vac-280Vac)±2%(APL mode)(90Vac-140Vac)±2%
Input Frequency Ranges 50Hz/60Hz(Auto-detection)
Max.Charging Current (Settable) 60A
Max.PV Open CircuitVoltage 500Vdc
PV Operating VoltageRange 450Vdc
MPPT Voltage Ranges 120-450Vdc
Max.PV Input Power 1000-2500W
Max.PV Input Current 22A
Amount of Power Shipped 50-80%
Communicate RS485、CAN
UPS Supports 10ms (Typical)
Weight 60Kg±1Kg(132.3lbs ± 1lbs)
Dimensions(L×W×H) 880mm×550mm×315mm
